KP370 Pirani Vacuum Module Gauge
Vacuum Module Gauge
Product
- THE SERIES KP370 is a combined Vacuum Gauge made using the Pirani & Piezo Sensor.
- It can be used in a variety of gas atmospheres.
SPECIFICATION
| Analog output | Log scale (0 ~ 7.18Vdc) Linear Scale ( 0 ~ 10Vdc ) |
| SET POINT RELAYS | 2 Point SPST (1A / 30VDC ,0.5A / 125VAC ) |
| POWER REQUIRED | DC24V / 200mA |
| OPTIONAL | 485 ASCII / 485 MODBUS |
| Application Sensor | KVC310 NTA PIRANI Gauge |
| Sensor Fitting Size | 1/8NPT, 15mmO,D, NW16KF, NW25KF 1/4VCR, 1.33CF, 2.75CF, 1/2VCR |
| Measurement Range | 1.0E-4 to 1500Torr |
